Ниже по ссылке находится Руководство пользователя снегоходов ARCTIC CAT на модели:
— Bearcat 570/570 XT/F 570/T570
— Bearcat Z1 XT/F6/F8/F1000/Z1/Z1 Turbo/TZ1/TZ1 Turbo
— Crossfire, M-600/800/1000
— CFR 800/1000
Вложения
-
3,9 MB
Просмотры: 12.307
280010
Новенький
- Регистрация
- 9 Май 2010
- Сообщения
- 43
- Реакции
- 0
- Возраст
- 38
- Местонахождение
-
Оренбург
- Имя
-
Дмитрий
- Техника
-
M800 2012 Sno Pro (был CF8 SP LE), KAWA 800SX
-
#2
Полезная штука в электронном виде, спасибо!
A1ex24
Новенький
- Регистрация
- 5 Янв 2016
- Сообщения
- 5
- Реакции
- 0
- Возраст
- 39
- Местонахождение
-
Пермь
- Имя
-
Алексей
-
#3
Добрый день!
Приобрёл снегоход ARCTIC CAT BEARCAT 570 LT 2006 г.в.
Не могу найти руководство по эксплуатации. Заранее спасибо!
